LabGig M2-96G thermal cycler for PCR scientific equipment
Blue-Ray Biotech

M2-96G PCR Amplifier

Model: M2-96G
The M2-96G PCR amplifier provides precise temperature control and an intelligent user operating system to achieve rapid and specific amplification of target DNA fragments.
Technical Key Features
  • Ultra-compact and portable PCR thermal cycler
  • Lightweight design (~1 kg) for field and lab use
  • Fast ramp rate with precise temperature control
  • Supports immediate PCR after sample collection
  • Simple one-button operation
  • Heated lid to prevent condensation
  • Fully programmable PCR protocols
  • Same performance as benchtop thermal cyclers
Full Specifications
  • Sample size Common PCR reaction tubes such as 0.2mL/0.1mL/flat cap/convex cap
  • Reaction system 10-100 μL
  • Heating module 96-well heating block
  • Module temperature control range 0-100℃
  • Gradient temperature control range 30-100℃ (the maximum temperature span for a single setting is 30℃)
  • Hot lid temperature range 40-110℃
  • Temperature accuracy ±0.25℃(35~100℃
  • Temperature uniformity ≤±0.35℃ (20s after reaching the constant temperature of 95℃)
  • Maximum heating and cooling rate 6.0°C/s; 4.5°C/s
  • Average heating and cooling rate 4.5℃/s; 3.5℃/s
  • Show 2000 items
  • Maximum number of cycles 99 times
  • Maximum number of steps ±0.1-5℃
  • Temperature increase/decrease 28kg
  • Time increment/decrement ±1-240s
  • Power outage protection Yes
  • Interface 1 RS232, 1 USB2.0, 1 network port
  • Size 264mm x 470mm x 259mm
  • Weight 16.5kg
  • Input power 220V/50HZ; 110V/60HZ
  • Maximum power 925W
